F4T (Tungsten / warm white)
제조사 CAMEO (GERMANY)
제품군 LED FRESNEL SPOT
모델명 F4T (Tungsten / warm white)
간략설명 Colour spectrum Tungsten , warm white
LED type 520 W (approx. 50,000 operating hours)
Colour temperature 3200 K

LED PWM Frequency Adjustable: 800, 1200, 2000, 3600, 12000, 25000 Hz

Dispersion Beam Angle: 12 - 40 ° , Field Angle: 24 - 47 °

Lens 250 mm Fresnel

DMX Functions Device Settings , Dimmer , Dimmer Curve , Dimmer Fine , strobe
Standalone modes Master / Slave mode , Static

Indicators OLED Display

Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
Power consumption 473 W

Housing material Die-cast aluminum
Cabinet colour Black
Protection class IP IP20

Cooling Comination of Heat Pipe and Temperature Controlled Fan

Luminous flux 29500 lm
Efficiency 59 lm/W
Ambient temperature (operating) -15 - 45 °C


Dimensions without mounting bracket

Width 410 mm
Height 364 mm
Length 433 mm
Weight 17,8 kg
Accessories (included) 8-way barndoor , gel frame , Power cord
관련링크 https://www.cameolight.com/en/solutions/install/static-lighting/theate…

F4T (Tungsten / warm white)상세정보

.
