F2 FC (RGBW)
제조사 CAMEO (GERMANY)
제품군 LED FRESNEL SPOT
모델명 F2 FC (RGBW)
간략설명 RGBW 240 W (ca. 50,000 Operating Hours)

Number of LEDs R: 18 PCS / G: 18 PCS / B: 16 PCS / W: 37 PCS
LED PWM Frequency 1200 Hz , 2000 Hz , 25000 Hz , 4000 Hz , 600 Hz , 6000 Hz

Dispersion Beam Angle: 17 ° - 53 ° , Field Angle: 30 ° - 87 °

Lens 200 mm Fresnel

DMX mode 10-channel CCT , 10-channel HSI , 14-channel , 3-channel CCT , 3-channel HSI , 4-channel , 7-channel CCT , 7-channel HSI , 8-channel , 9-channel
DMX Functions CCT , Colour macros , Device Settings , Dim to Warm , Dimmer , Dimmer Curve , Dimmer Fine , Hue Saturation , RGBW , RGBW Fine , strobe

Standalone modes Loop , Master / Slave mode , Static

Indicators OLED Display

Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
Power consumption 250 W
power factor 0.95 / 230 V , 0.99 / 120 V

Housing material Die-cast aluminum
Cabinet colour Black

Protection class IP 20

Cooling Comination of Heat Pipe and Temperature Controlled Fan
Luminous flux 6500 lm
Efficiency 27 lm/W
Ambient temperature (operating) -15 - 45 °C


Dimensions including Mounting Bracket

Width 302 mm
Height 433 mm
Length 442 mm
Weight 9 kg
Accessories (included) 8-way barndoor , gel frame , Power cord
관련링크 https://www.cameolight.com/en/solutions/install/static-lighting/theate…

F2 FC (RGBW)상세정보

.
